Pressure Transducer – 265 Series
The 265 is a very low pressure transducer for ranges as low as 6.35 mm (0.25″) W.C. and feature ±1% full-scale static accuracy. Primarily used in Building Energy Management these transducers are capable of measuring pressures and flows with the accuracy necessary for proper building pressurization and air flow control. 265 series transducers utilize an all-stainless steel micro-tig welded sensor that allows up to .69 bar (10 psi) overpressure (in either direction) with no damage to the unit. All sensor components have thermally matched coefficients, resulting in improved temperature performance and excellent long-term stability.
Technical Spec
| Supply Voltage (Vs) | 9-30Vdc |
|---|---|
| Proof Pressure | 700mbar |
| Output | 0-5Vdc or 0-10Vdc (3 wire) |
| 4-20mA (2 wire) | |
| Pressure Port | 1/4” Fitting |
| Enclosure | Fire Retardant Glass-Filled Polyester; Conduit Enclosure Available |
Applications
- HVAC
- Energy Management Systems
- Variable Air Volume and Fan Control (VAV)
- Environmental Pollution Control
- Static Duct and Clean Room Pressures
- Oven Pressurization and Furnace Draft Controls
