Pressure Transducer – 3200 OEM Series with Temperature Output Option
For OEMs that need consistent high levels of performance, reliability and stability the 3200 series sputtered thin film pressure transducer unit offers an unbeatable price/performance ratio in a small package size. It features all-stainless steel wetted parts, a broad selection of electrical and pressure connections, and a wide choice of electrical outputs to allow stock configurations suitable for most applications without modification. At the heart of this series is a sputter element that also provides exceptional temperature specifications. The manufacturing process for the 3100 series includes the latest automated equipment, producing the most consistent and best price to performance sensor on the market today.
Additionally, 3200 series transmitters feature thicker diaphragms and a pressure restrictor to withstand the rigours of cavitations or extreme pressure spikes, delivering years of reliable and stable performance in pulsating applications.
The compact construction of this series makes it ideal for installation where space is at a premium. And it is fully RoHS compliant.
Technical Spec
| Pressure ranges | 0 - 10 Bar to 0 - 600 Bar |
|---|---|
| Output options | 4-20 mA, 1-5v, 0-10v, 1-6v, 0.5-4.5v Non ratiometric, 0.5 - 4.5 ratiometric, 0-5v |
| Supply voltage | 10 to 30Vdc (5Vdc for ratiometric) |
| Diaphragm | 17-4 PH Stainless steel |
| Fitting | 17-4 PH Stainless steel (Various connection options available) |
Related Categories
Advantages
- Extremely robust
- Optional temperature output
- Many electrical connection and process connection options
- Thicker diaphragms and pressure restrictor to withstand pressure spikes
Applications
- Demanding pressure applications
